CSP
| Product information | |||||||||
| No. | Sort | Product Name | Dimension (mm) | Emitted Color | Forward current(mA) | Forward Voltage(V) | Luminous Intensity(mcd) | Dominant Wavelength/CIE | |
| 1 | CSP | HWCSP0603BBH-S | 0.62*0.32*0.15 | BLUE | 2 | 2.6-2.8 | 40-70 | 445-460 |  |
| 2 | CSP | HWCSP0603WBH-S | 0.62*0.32*0.15 | WHITE | 1 | 2.4-3.1 | 56-140 | X:0.30typ Y:0.30typ |  |
| 3 | CSP | HWCSP0804RGBBH-S | 0.8*0.45*0.15 | RGB | 5 | R:1.6-2.6 G:2.0-3.2 B:2.0-3.2 | R:90-224 G:280-710 B:56-81 | R:619.5-629.5 G:527.5-533.5 B:464.5-473.5 |  |
